Common class for all classes which objects can be archived or restored from archive. More...
#include <ISerializable.h>
Public Member Functions | |
| virtual bool | Serialize (IArchive &archive)=0 |
| Load or store state of this object as a archive stream. | |
| virtual quint32 | GetMinimalVersion (int versionId) const |
| Get minimal needed version to correct storing of this data. | |
 Public Member Functions inherited from istd::IChangeable | |
| virtual int | GetSupportedOperations () const |
| Get set of flags for supported operations. | |
| virtual bool | CopyFrom (const IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS) |
| Copy this object from another one. | |
| virtual bool | IsEqual (const IChangeable &object) const |
| Compare this object with another object. | |
| virtual istd::TUniqueInterfacePtr< istd::IChangeable > | CloneMe (CompatibilityMode mode=CM_WITHOUT_REFS) const |
| Make a copy of this object. | |
| virtual bool | ResetData (CompatibilityMode mode=CM_WITHOUT_REFS) |
| Reset data to its default state. | |
| virtual void | BeginChanges (const ChangeSet &changeSet) |
| Starts the change transaction. | |
| virtual void | EndChanges (const ChangeSet &changeSet) |
| Ends the change transaction. | |
| virtual void | BeginChangeGroup (const ChangeSet &changeSet) |
| Starts group of changes. | |
| virtual void | EndChangeGroup (const ChangeSet &changeSet) |
| Ends group of changes. | |
| Public Member Functions inherited from istd::IPolymorphic | |
| virtual | ~IPolymorphic () |
Additional Inherited Members | |
| Public Types inherited from istd::IChangeable | |
| enum | ChangeFlags { CF_ACF_INTERNAL = 0 , CF_ALL_DATA , CF_ANY , CF_DESTROYING , CF_DELEGATED , CF_NO_UNDO } |
| Data model change notification flags. More... | |
| enum | SupportedOperations { SO_NONE = 0 , SO_OBSERVE = 1 << 0 , SO_COPY = 1 << 1 , SO_CLONE = 1 << 2 , SO_COMPARE = 1 << 3 , SO_RESET = 1 << 4 } |
| Flags for supported operations. More... | |
| enum | CompatibilityMode { CM_STRICT , CM_WITHOUT_REFS , CM_WITH_REFS , CM_CONVERT } |
| Control how relationship betweeen objects are interpreted. More... | |
| typedef QMultiMap< QByteArray, QVariant > | ChangeInfoMap |
| Static Public Member Functions inherited from istd::IChangeable | |
| static const ChangeSet & | GetNoChanges () |
| Get empty set of changes. | |
| static const ChangeSet & | GetAnyChange () |
| Get anonymous change set. | |
| static const ChangeSet & | GetAllChanges () |
| Get anonymous change set. | |
| static const ChangeSet & | GetDelegatedChanges () |
| Get delegated change set. | |
| Protected Member Functions inherited from istd::IChangeable | |
| virtual void | OnBeginChanges () |
| Callback function for begin change event. | |
| virtual void | OnEndChanges (const ChangeSet &changeSet) |
| Callback function for end change event. | |
Detailed Description
Common class for all classes which objects can be archived or restored from archive.
Definition at line 23 of file ISerializable.h.
Member Function Documentation
◆ GetMinimalVersion()
|
inlinevirtual |
Get minimal needed version to correct storing of this data.
In implementation shold be calculated maximum version of this and composed component.
Reimplemented in icomp::CRegistry, iprm::CParamsSet, and iprm::CVariableParamComp.
Definition at line 42 of file ISerializable.h.
◆ Serialize()
|
pure virtual |
Load or store state of this object as a archive stream.
Type of operation is depending on archive type.
- See also
- iser::IArchive
Implemented in CAbComp, i2d::CAffineTransformation2d, i2d::CAnnulus, i2d::CAnnulusSegment, i2d::CArc, i2d::CCircle, i2d::CDataNodePolylineBase, i2d::CGraphData2d, i2d::CLabel, i2d::CLine2d, i2d::CObject2dProxyComp, i2d::COrientedCircle, i2d::CParallelogram, i2d::CPolyline, i2d::CPolypoint, i2d::CPosition2d, i2d::CQuadrangle, i2d::CRectangle, i2d::CTubeNode, iattr::CAttributesManager, iattr::TAttribute< Value >, iattr::TMultiAttribute< Value >, ibase::CObjectQueueComp, ibase::TFactorisableContainer< InterfaceClass >, ibase::TSerializableContainer< ItemClass, ContainerType >, ibase::TSerializableContainer< QPair< istd::TSmartPtr< InterfaceClass >, QByteArray > >, icmm::CCieLabColor, icmm::CCmy, icmm::CCmyk, icmm::CHsv, icmm::CIlluminant, icmm::CLab, icmm::CRgb, icmm::CRgbColor, icmm::CSpectralColor, icmm::CSpectralColorSpecificationBase, icmm::CSpectrum, icmm::CSpectrumInfo, icmm::CSubstractiveColorModel, icmm::CTristimulusSpecification, icmm::CVarColor, icmm::TComposedColor< Size >, icmm::TComposedColor< 3 >, icmm::TComposedColor< 4 >, icomp::CCachedEnvironmentManager, icomp::CComponentAddress, icomp::CRegistry, icomp::CRegistryElement, icomp::CXpcModel, idoc::CStandardDocumentMetaInfo, idoc::CTextDocumentComp, idoc::TMultiPageDocumentWrap< Base >, idoc::TMultiPageDocumentWrap< idoc::IMultiPageDocument >, ifile::CFileNameParam, ifile::CRelativeFileNameParamComp, ifile::CSystemLocationComp, iimg::CBitmapBase, iimg::CScanlineMask, ilog::CExtMessage, ilog::CMessage, ilog::CTracingConfigurationComp, ilog::TExtMessage< Element >, imath::CGeneralUnitInfo, imath::TFulcrumGrid< Position, Fulcrums >, imath::TFulcrumGrid< Argument, Fulcrums >, imath::TMultidimensionalPolynomial< Dimensions, Element >, iprm::CDelegatedEnableableParamComp, iprm::CEnableableParam, iprm::CIdParam, iprm::CMultiParamsManagerComp, iprm::CNameParam, iprm::COptionsManager, iprm::CParamsManagerComp, iprm::CParamsManagerCompBase::UuidParam, iprm::CParamsManagerCompBase::ParamSet, iprm::CParamsManagerCompBase::SelectedParams, iprm::CParamsSet, iprm::CParamsSetDelegatorComp, iprm::CSelectableParamsSetComp, iprm::CSelectionParam, iprm::CTextParam, iprm::CTextParamComp, iprm::CVariableParamComp, iqtgui::CHierarchicalCommand, and Model.
Referenced by ifile::TFileSerializerComp< ReadArchive, WriteArchive >::LoadFromFile(), ifile::TXmlFileSerializerComp< ReadArchive, WriteArchive >::LoadFromFile(), ifile::TDeviceBasedSerializerComp< ReadArchive, WriteArchive >::ReadFromDevice(), ibase::TFactorisableContainer< InterfaceClass >::SerializeItem(), and idoc::TMultiPageDocumentWrap< Base >::SerializePage().
The documentation for this class was generated from the following file:
- Acf/Include/iser/ISerializable.h
