Interactive log viewer component with filtering and commands. More...

#include <CLogGuiComp.h>

Inheritance diagram for iloggui::CLogGuiComp:

Public Types
enum	ColumnType { CT_ICON , CT_TIME , CT_SOURCE , CT_MESSAGE }

typedef iqtgui::TDesignerGuiCompBase< Ui::CLogGuiComp >	BaseClass
	Base class typedef for GUI functionality.

typedef ilog::CMessageContainer	BaseClass2
	Base class typedef for container functionality.

Public Types inherited from iqtgui::TGuiComponentBase< WidgetType >
typedef CGuiComponentBase	BaseClass

Public Types inherited from iqtgui::CGuiComponentBase
typedef TMakeIconProviderCompWrap< ibase::TLocalizableWrap< icomp::CComponentBase > >	BaseClass

Public Types inherited from iqtgui::TMakeIconProviderCompWrap< ibase::TLocalizableWrap< icomp::CComponentBase > >
typedef ibase::TLocalizableWrap< icomp::CComponentBase >	BaseClass

Public Types inherited from iqtgui::TDesignSchemaHandlerWrap< Base >
typedef Base	BaseClass

Public Types inherited from istd::THierarchicalBase< IHierarchicalMessageContainer >
typedef istd::TChangeDelegator< IHierarchicalMessageContainer >	BaseClass

Public Types inherited from istd::TChangeDelegator< Base >
typedef Base	BaseClass

typedef CChangeDelegator	BaseClass2

Public Types inherited from istd::CChangeDelegator
typedef istd::IChangeable	BaseClass

Public Types inherited from istd::IChangeable
enum	ChangeFlags { CF_ACF_INTERNAL = 0 , CF_ALL_DATA , CF_ANY , CF_DESTROYING , CF_DELEGATED , CF_NO_UNDO }
	Data model change notification flags. More...

enum	SupportedOperations { SO_NONE = 0 , SO_OBSERVE = 1 << 0 , SO_COPY = 1 << 1 , SO_CLONE = 1 << 2 , SO_COMPARE = 1 << 3 , SO_RESET = 1 << 4 }
	Flags for supported operations. More...

enum	CompatibilityMode { CM_STRICT , CM_WITHOUT_REFS , CM_WITH_REFS , CM_CONVERT }
	Control how relationship betweeen objects are interpreted. More...

typedef QMultiMap< QByteArray, QVariant >	ChangeInfoMap

Public Types inherited from ilog::IMessageConsumer
typedef istd::TSharedInterfacePtr< istd::IInformationProvider >	MessagePtr
	Shared pointer type for message objects.

Public Types inherited from ibase::ICommandsProvider
enum	ChangeFlags { CF_COMMANDS = 0x62b7e8 }

Signals
void	EmitAddMessage (const MessagePtr &messagePtr)

void	EmitClearAction ()

Public Member Functions
	CLogGuiComp ()

virtual const ibase::IHierarchicalCommand *	GetCommands () const override
	Get list of menu commands.

Public Member Functions inherited from iqtgui::TGuiComponentBase< WidgetType >
	TGuiComponentBase ()

virtual WidgetType *	GetQtWidget () const

virtual QWidget *	CreateQtWidget (QWidget *parentPtr) override
	Create slave widget object.

Public Member Functions inherited from iqtgui::CGuiComponentBase
	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, IVisualStatus, ExtractVisualStatus)

	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, istd::IChangeable, ExtractVisualStatus)

	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, imod::IModel, ExtractVisualStatus)

	CGuiComponentBase ()

bool	IsGuiShown () const

virtual bool	IsGuiCreated () const override
	Checks if the GUI has been initialized and created.

virtual bool	CreateGui (QWidget *parentPtr) override
	Initializes the GUI and connects it to the parent widget.

virtual bool	DestroyGui () override
	Releases GUI resources and disconnects from the parent.

virtual QWidget *	GetWidget () const override
	Gets access to the internal QWidget object.

virtual void	OnTryClose (bool *ignoredPtr=NULL) override
	Called when the application is attempting to close.

Public Member Functions inherited from iqtgui::TDesignSchemaHandlerWrap< Base >
	TDesignSchemaHandlerWrap ()

virtual void	EnableDesignHandler (bool enable=true)
	If enabled, listen to the design schema change events from the application context.

Public Member Functions inherited from iqtgui::CIconProvider
virtual QIcon	GetIcon (const QString &iconName) const

virtual QString	GetIconPath (const QString &iconName) const

virtual QString	GetStyleSheetPath (const QString &styleSheetPath) const

QByteArray	GetCurrentThemeId () const

void	SetThemeId (const QByteArray &themeId)

Public Member Functions inherited from istd::IPolymorphic
virtual	~IPolymorphic ()

Public Member Functions inherited from ilog::CMessageContainer
	CMessageContainer ()

	CMessageContainer (const CMessageContainer &container)

CMessageContainer &	operator= (const CMessageContainer &container)

int	GetMessagesCount () const
	Get the number of messages in the container.

virtual void	AddChildContainer (IHierarchicalMessageContainer *childContainerPtr)
	Add a child message container to this object.

void	SetSlaveConsumer (ilog::IMessageConsumer *consumerPtr)
	Set slave message consumer.

void	SetMaxMessageCount (int maxMessageCount=-1)
	Set maximal number of messages in the container.

virtual bool	Serialize (iser::IArchive &archive) override

virtual istd::IInformationProvider::InformationCategory	GetWorstCategory () const override

virtual Messages	GetMessages () const override

virtual int	GetChildsCount () const override

virtual IHierarchicalMessageContainer *	GetChild (int index) const override

virtual int	GetSupportedOperations () const override
	Get set of flags for supported operations.

virtual bool	CopyFrom (const istd::IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS) override
	Copy this object from another one.

virtual bool	IsEqual (const istd::IChangeable &object) const override
	Compare this object with another object.

virtual istd::TUniqueInterfacePtr< istd::IChangeable >	CloneMe (CompatibilityMode mode=CM_WITHOUT_REFS) const override
	Make a copy of this object.

virtual bool	ResetData (CompatibilityMode mode) override
	Reset data to its default state.

Public Member Functions inherited from istd::THierarchicalBase< IHierarchicalMessageContainer >
	THierarchicalBase ()

virtual void	SetParentPtr (typename Base::InterfaceType *parentPtr)

virtual int	GetHierarchicalFlags () const override

virtual typename Base::InterfaceType *	GetParent () const override

Public Member Functions inherited from istd::TChangeDelegator< Base >
	TChangeDelegator ()

	TChangeDelegator (istd::IChangeable *slavePtr)

virtual void	OnBeginChanges () override
	Callback function for begin change event.

virtual void	OnEndChanges (const istd::IChangeable::ChangeSet &changeSet) override
	Callback function for end change event.

Public Member Functions inherited from istd::CChangeDelegator
	CChangeDelegator ()

	CChangeDelegator (istd::IChangeable *slavePtr)

virtual void	SetSlavePtr (istd::IChangeable *slavePtr) override
	Sets the slave object pointer for change delegation.

virtual istd::IChangeable *	GetSlavePtr () const override
	Gets the slave object pointer.

Public Member Functions inherited from istd::IChangeable
virtual void	BeginChanges (const ChangeSet &changeSet)
	Starts the change transaction.

virtual void	EndChanges (const ChangeSet &changeSet)
	Ends the change transaction.

virtual void	BeginChangeGroup (const ChangeSet &changeSet)
	Starts group of changes.

virtual void	EndChangeGroup (const ChangeSet &changeSet)
	Ends group of changes.

Protected Types
enum	MessageMode { MM_INFO = istd::IInformationProvider::IC_NONE , MM_WARNING = istd::IInformationProvider::IC_WARNING , MM_ERROR = istd::IInformationProvider::IC_ERROR , MM_ALL = istd::IInformationProvider::IC_CRITICAL }

enum	ActionType { AT_CLEAR , AT_EXPORT , AT_DIAGNOSTICS }

enum	DataRole { DR_CATEGORY = Qt::UserRole }

enum	CommandGroup { CG_FILTER = 5000 , CG_EDIT }

Protected Types inherited from ilog::CMessageContainer
typedef QVector< IHierarchicalMessageContainer * >	Childs

Protected Slots
virtual void	OnAddMessage (const MessagePtr &messagePtr)

virtual void	OnMessageModeChanged ()

virtual void	OnClearAction ()

virtual void	OnExportAction ()

void	OnRemoveMessagesTimer ()

void	EnableDiagnosticMessages (bool state)

void	on_FilterText_textChanged (const QString &filterText)

Protected Member Functions
virtual QTreeWidgetItem *	CreateGuiItem (const istd::IInformationProvider &message)
	Create GUI item corresponding to specified message.

virtual QIcon	GetCategoryIcon (int category) const
	Get icons corresponding to specified information category.

virtual QIcon	GetActionIcon (int functionType) const
	Get icons corresponding to specified log action.

virtual QString	GetCategoryText (int category) const
	Get text corresponding to specified information category.

virtual void	SetupCommands ()
	Setup log gui commands.

virtual void	SetCommandsVisuals ()
	Setup log gui command visuals.

virtual bool	IsMessageSupported (int messageCategory=-1, int messageId=-1, const istd::IInformationProvider *messagePtr=NULL) const override
	Check if a message is supported by this consumer.

virtual void	AddMessage (const MessagePtr &messagePtr) override
	Adds a message to this consumer.

virtual void	ClearMessages () override

virtual void	OnGuiCreated () override
	Called just after GUI is initialized.

virtual void	OnGuiDestroyed () override
	Called just before GUI is released.

virtual void	OnGuiRetranslate () override
	Called from widget event filter when GUI should be retranslated.

virtual void	OnGuiDesignChanged () override

virtual void	OnComponentCreated () override

Protected Member Functions inherited from iqtgui::CGuiComponentBase
virtual void	OnGuiShown ()
	Called from widget event filter when slave widget is shown.

virtual void	OnGuiHidden ()
	Called from widget event filter when slave widget is hidden.

virtual bool	OnKeyPressed (QKeyEvent *event)
	Called from widget event filter when key is pressed.

virtual void	OnRetranslate ()
	Called when non-GUI elements (like commands) should be retranslated.

void	SetStatusIcon (const QIcon &icon)
	Set status icon;.

void	SetStatusText (const QString &text)
	Set status text;.

void	SetDefaultVisualStatus ()

virtual void	OnLanguageChanged () override

virtual void	OnDesignSchemaChanged (const QByteArray &themeId) override

virtual bool	eventFilter (QObject sourcePtr, QEvent eventPtr) override

virtual void	OnComponentDestroyed () override

Protected Member Functions inherited from iqtgui::CIconProvider
virtual QIcon	CreateIcon (const QString &iconName) const

Protected Attributes
QAction *	m_infoActionPtr

QAction *	m_warningActionPtr

QAction *	m_errorActionPtr

QAction *	m_clearActionPtr

QAction *	m_exportActionPtr

QAction *	m_diagnosticModeActionPtr

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_rootCommands

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_infoCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_warningCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_errorCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_clearCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_exportCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand >	m_diagnosticCommand

Protected Attributes inherited from iqtgui::CGuiComponentBase
imod::TModelWrap< VisualStatus >	m_visualStatus

Protected Attributes inherited from ilog::CMessageContainer
Messages	m_messages

Childs	m_childContainers

ilog::IMessageConsumer *	m_slaveConsumerPtr

int	m_maxMessagesCount

int	m_worstCategory

Protected Attributes inherited from istd::THierarchicalBase< IHierarchicalMessageContainer >
typename Base::InterfaceType *	m_parentPtr

Additional Inherited Members
Static Public Member Functions inherited from ilog::CMessageContainer
template<typename MessageType >
static bool	RegisterMessageType (const QByteArray &messageTypeId=QByteArray())
	Register a new message type.

Static Public Member Functions inherited from istd::IChangeable
static const ChangeSet &	GetNoChanges ()
	Get empty set of changes.

static const ChangeSet &	GetAnyChange ()
	Get anonymous change set.

static const ChangeSet &	GetAllChanges ()
	Get anonymous change set.

static const ChangeSet &	GetDelegatedChanges ()
	Get delegated change set.

Detailed Description

Interactive log viewer component with filtering and commands.

CLogGuiComp is the primary log viewing component in the iloggui library. It provides a full-featured Qt widget for displaying, filtering, searching, and exporting log messages.

The component combines:

QTreeWidget-based display with multiple columns (icon, time, source, message)
Message storage via CMessageContainer
Filter controls (info/warning/error modes)
Text search
Command integration for toolbars/menus
Export functionality
Diagnostic mode support

For detailed documentation including configuration, usage examples, and integration patterns, see the iloggui library documentation.

Quick Example: // Create log GUI component

istd::TSharedInterfacePtr<iloggui::CLogGuiComp> logGui(

new iloggui::CLogGuiComp);

// Get widget for display

QWidget* widget = logGui->GetWidget();

mainWindow->setCentralWidget(widget);

// Add messages

logGui->AddMessage(messagePtr);

iloggui::CLogGuiComp
Interactive log viewer component with filtering and commands.
Definition CLogGuiComp.h:70

istd::TSharedInterfacePtr
Shared ownership smart pointer for interface types.
Definition TInterfacePtr.h:507

See also: iloggui - Logging GUI Components, ilog::CMessageContainer, iqtgui::TDesignerGuiCompBase

Definition at line 66 of file CLogGuiComp.h.

Member Typedef Documentation

◆ BaseClass

typedef iqtgui::TDesignerGuiCompBase<Ui::CLogGuiComp> iloggui::CLogGuiComp::BaseClass

Base class typedef for GUI functionality.

Definition at line 75 of file CLogGuiComp.h.

◆ BaseClass2

typedef ilog::CMessageContainer iloggui::CLogGuiComp::BaseClass2

Base class typedef for container functionality.

Definition at line 78 of file CLogGuiComp.h.

Member Enumeration Documentation

◆ ActionType

enum iloggui::CLogGuiComp::ActionType

protected

Enumerator
AT_CLEAR
AT_EXPORT
AT_DIAGNOSTICS

Definition at line 123 of file CLogGuiComp.h.

◆ ColumnType

enum iloggui::CLogGuiComp::ColumnType

Enumerator
CT_ICON
CT_TIME
CT_SOURCE
CT_MESSAGE

Definition at line 80 of file CLogGuiComp.h.

◆ CommandGroup

enum iloggui::CLogGuiComp::CommandGroup

protected

Enumerator
CG_FILTER
CG_EDIT

Definition at line 207 of file CLogGuiComp.h.

◆ DataRole

enum iloggui::CLogGuiComp::DataRole

protected

Enumerator
DR_CATEGORY

Definition at line 130 of file CLogGuiComp.h.

◆ MessageMode

enum iloggui::CLogGuiComp::MessageMode

protected

Enumerator
MM_INFO
MM_WARNING
MM_ERROR
MM_ALL

Definition at line 115 of file CLogGuiComp.h.

Constructor & Destructor Documentation

◆ CLogGuiComp()

iloggui::CLogGuiComp::CLogGuiComp ( )

Member Function Documentation

◆ AddMessage()

virtual void iloggui::CLogGuiComp::AddMessage ( const MessagePtr & messagePtr )

overrideprotectedvirtual

Adds a message to this consumer.

This method transfers ownership of the message to the consumer via shared pointer. The consumer may store, display, forward, or otherwise process the message.

Most implementations deliver messages asynchronously using Qt signals/slots to ensure thread safety when messages are added from worker threads.

Parameters

messagePtr Shared pointer to the message. After this call, the message is owned by the shared pointer and will be automatically deleted when no longer referenced.

Note: This method should not throw exceptions. Implementations should handle errors gracefully (e.g., by logging internally or ignoring invalid messages).

Warning: The message object should not be modified after being added to a consumer, as multiple consumers may reference the same message object.

Example: // Create message with shared pointer

istd::TSharedInterfacePtr<ilog::CMessage> msg(

new ilog::CMessage(

istd::IInformationProvider::IC_ERROR,

2001,

"File not found: config.xml",

"ConfigLoader"

)

);

// Add to consumer (ownership transferred)

consumer->AddMessage(msg);

// msg can still be used as shared pointer maintains reference count

// but don't modify the message after adding it

ilog::CMessage
Basic implementation of the istd::IInformationProvider interface for log messages.
Definition CMessage.h:80

istd::IInformationProvider::IC_ERROR
@ IC_ERROR
Information about error, processing could not be done correctly.
Definition IInformationProvider.h:44

See also: IsMessageSupported()

Reimplemented from ilog::CMessageContainer.

◆ ClearMessages()

virtual void iloggui::CLogGuiComp::ClearMessages ( )

overrideprotectedvirtual

Reimplemented from ilog::CMessageContainer.

◆ CreateGuiItem()

virtual QTreeWidgetItem * iloggui::CLogGuiComp::CreateGuiItem ( const istd::IInformationProvider & message )

protectedvirtual

Create GUI item corresponding to specified message.

◆ EmitAddMessage

void iloggui::CLogGuiComp::EmitAddMessage ( const MessagePtr & messagePtr )

signal

◆ EmitClearAction

void iloggui::CLogGuiComp::EmitClearAction ( )

signal

◆ EnableDiagnosticMessages

void iloggui::CLogGuiComp::EnableDiagnosticMessages ( bool state )

protectedslot

◆ GetActionIcon()

virtual QIcon iloggui::CLogGuiComp::GetActionIcon ( int functionType ) const

protectedvirtual

Get icons corresponding to specified log action.

◆ GetCategoryIcon()

virtual QIcon iloggui::CLogGuiComp::GetCategoryIcon ( int category ) const

protectedvirtual

Get icons corresponding to specified information category.

◆ GetCategoryText()

virtual QString iloggui::CLogGuiComp::GetCategoryText ( int category ) const

protectedvirtual

Get text corresponding to specified information category.

◆ GetCommands()

virtual const ibase::IHierarchicalCommand * iloggui::CLogGuiComp::GetCommands ( ) const

overridevirtual

Get list of menu commands.

These commands will be integrated in global menu system, independent from actual selected view. For support of normal pull down menu, depth of this tree structure should be at least 3.

Reimplemented from ibase::ICommandsProvider.

◆ IsMessageSupported()

virtual bool iloggui::CLogGuiComp::IsMessageSupported	(	int	messageCategory = `-1`,
		int	messageId = `-1`,
		const istd::IInformationProvider *	messagePtr = `NULL`
	)		const

overrideprotectedvirtual

Check if a message is supported by this consumer.

This method allows consumers to filter messages based on category, ID, or the complete message object. It's used to determine whether a message should be sent to this consumer before actually adding it.

Parameters

messageCategory Category of message (IC_NONE, IC_INFO, IC_WARNING, IC_ERROR, IC_CRITICAL) or -1 if category check should be skipped.

See also: istd::IInformationProvider::InformationCategory.

Parameters

messageId	Numeric ID of message or -1 if ID check should be skipped. Message IDs are application-defined for filtering and routing.
messagePtr	Optional pointer to complete message object for detailed inspection, or NULL if not needed. The consumer will not store this pointer.

Returns: true if the message is supported and should be sent to this consumer, false if the message should be filtered out.

Note: Returning false does not indicate an error; it simply means the message doesn't match the consumer's filter criteria.

Example: // Check if consumer accepts warnings

if (consumer->IsMessageSupported(istd::IInformationProvider::IC_WARNING)) {

// Consumer accepts warnings

}

// Check specific message ID

if (consumer->IsMessageSupported(-1, 5001)) {

// Consumer accepts message ID 5001

}

// Check complete message

ilog::CMessage msg(istd::IInformationProvider::IC_INFO, 1, "Test", "Source");

if (consumer->IsMessageSupported(-1, -1, &msg)) {

// Consumer accepts this specific message

}

istd::IInformationProvider::IC_INFO
@ IC_INFO
Normal information level.
Definition IInformationProvider.h:36

istd::IInformationProvider::IC_WARNING
@ IC_WARNING
Information about warning, processing could be done.
Definition IInformationProvider.h:40

Reimplemented from ilog::CMessageContainer.

◆ on_FilterText_textChanged

void iloggui::CLogGuiComp::on_FilterText_textChanged ( const QString & filterText )

protectedslot

◆ OnAddMessage

virtual void iloggui::CLogGuiComp::OnAddMessage ( const MessagePtr & messagePtr )

protectedvirtualslot

◆ OnClearAction

virtual void iloggui::CLogGuiComp::OnClearAction ( )

protectedvirtualslot

◆ OnComponentCreated()

virtual void iloggui::CLogGuiComp::OnComponentCreated ( )

overrideprotectedvirtual

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnExportAction

virtual void iloggui::CLogGuiComp::OnExportAction ( )

protectedvirtualslot

◆ OnGuiCreated()

virtual void iloggui::CLogGuiComp::OnGuiCreated ( )

overrideprotectedvirtual

Called just after GUI is initialized.

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnGuiDesignChanged()

virtual void iloggui::CLogGuiComp::OnGuiDesignChanged ( )

overrideprotectedvirtual

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnGuiDestroyed()

virtual void iloggui::CLogGuiComp::OnGuiDestroyed ( )

overrideprotectedvirtual

Called just before GUI is released.

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnGuiRetranslate()

virtual void iloggui::CLogGuiComp::OnGuiRetranslate ( )

overrideprotectedvirtual

Called from widget event filter when GUI should be retranslated.

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnMessageModeChanged

virtual void iloggui::CLogGuiComp::OnMessageModeChanged ( )

protectedvirtualslot

◆ OnRemoveMessagesTimer

void iloggui::CLogGuiComp::OnRemoveMessagesTimer ( )

protectedslot

◆ SetCommandsVisuals()

virtual void iloggui::CLogGuiComp::SetCommandsVisuals ( )

protectedvirtual

Setup log gui command visuals.

◆ SetupCommands()

virtual void iloggui::CLogGuiComp::SetupCommands ( )

protectedvirtual

Setup log gui commands.

Member Data Documentation

◆ m_clearActionPtr

QAction* iloggui::CLogGuiComp::m_clearActionPtr

protected

Definition at line 217 of file CLogGuiComp.h.

◆ m_clearCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_clearCommand

protected

Definition at line 226 of file CLogGuiComp.h.

◆ m_diagnosticCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_diagnosticCommand

protected

Definition at line 228 of file CLogGuiComp.h.

◆ m_diagnosticModeActionPtr

QAction* iloggui::CLogGuiComp::m_diagnosticModeActionPtr

protected

Definition at line 219 of file CLogGuiComp.h.

◆ m_errorActionPtr

QAction* iloggui::CLogGuiComp::m_errorActionPtr

protected

Definition at line 216 of file CLogGuiComp.h.

◆ m_errorCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_errorCommand

protected

Definition at line 225 of file CLogGuiComp.h.

◆ m_exportActionPtr

QAction* iloggui::CLogGuiComp::m_exportActionPtr

protected

Definition at line 218 of file CLogGuiComp.h.

◆ m_exportCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_exportCommand

protected

Definition at line 227 of file CLogGuiComp.h.

◆ m_infoActionPtr

QAction* iloggui::CLogGuiComp::m_infoActionPtr

protected

Definition at line 214 of file CLogGuiComp.h.

◆ m_infoCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_infoCommand

protected

Definition at line 223 of file CLogGuiComp.h.

◆ m_rootCommands

istd::TDelPtr<iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_rootCommands

protected

Definition at line 222 of file CLogGuiComp.h.

◆ m_warningActionPtr

QAction* iloggui::CLogGuiComp::m_warningActionPtr

protected

Definition at line 215 of file CLogGuiComp.h.

◆ m_warningCommand

istd::TDelPtr< iqtgui::CHierarchicalCommand> iloggui::CLogGuiComp::m_warningCommand

protected

Definition at line 224 of file CLogGuiComp.h.

The documentation for this class was generated from the following file:

Acf/Include/iloggui/CLogGuiComp.h

Public Types

Signals

Public Member Functions

Protected Types

Protected Slots

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ BaseClass

◆ BaseClass2

Member Enumeration Documentation

◆ ActionType

◆ ColumnType

◆ CommandGroup

◆ DataRole

◆ MessageMode

Constructor & Destructor Documentation

◆ CLogGuiComp()

Member Function Documentation

◆ AddMessage()

◆ ClearMessages()

◆ CreateGuiItem()

◆ EmitAddMessage

◆ EmitClearAction

◆ EnableDiagnosticMessages

◆ GetActionIcon()

◆ GetCategoryIcon()

◆ GetCategoryText()

◆ GetCommands()

◆ IsMessageSupported()

◆ on_FilterText_textChanged

◆ OnAddMessage

◆ OnClearAction

◆ OnComponentCreated()

◆ OnExportAction

◆ OnGuiCreated()

◆ OnGuiDesignChanged()

◆ OnGuiDestroyed()

◆ OnGuiRetranslate()

◆ OnMessageModeChanged

◆ OnRemoveMessagesTimer

◆ SetCommandsVisuals()

◆ SetupCommands()

Member Data Documentation

◆ m_clearActionPtr

◆ m_clearCommand

◆ m_diagnosticCommand

◆ m_diagnosticModeActionPtr

◆ m_errorActionPtr

◆ m_errorCommand

◆ m_exportActionPtr

◆ m_exportCommand

◆ m_infoActionPtr

◆ m_infoCommand

◆ m_rootCommands

◆ m_warningActionPtr

◆ m_warningCommand
