Component for construction of a tool bar for a given commands provider. More...

#include <CCommandsToolBarGuiComp.h>

Inheritance diagram for iqtgui::CCommandsToolBarGuiComp:

Public Types
typedef CToolBarGuiCompBase	BaseClass

Public Types inherited from iqtgui::CToolBarGuiCompBase
typedef iqtgui::TGuiComponentBase< QToolBar >	BaseClass

Public Types inherited from iqtgui::TGuiComponentBase< QToolBar >
typedef CGuiComponentBase	BaseClass

Public Types inherited from iqtgui::CGuiComponentBase
typedef TMakeIconProviderCompWrap< ibase::TLocalizableWrap< icomp::CComponentBase > >	BaseClass

Public Types inherited from iqtgui::TMakeIconProviderCompWrap< ibase::TLocalizableWrap< icomp::CComponentBase > >
typedef ibase::TLocalizableWrap< icomp::CComponentBase >	BaseClass

Public Types inherited from iqtgui::TDesignSchemaHandlerWrap< Base >
typedef Base	BaseClass

Public Types inherited from iqtgui::IMainWindowComponent
enum	WindowComponentFlags { WCF_NONE = 0 , WCF_CLOSABLE = 1 , WCF_MOVEABLE = 2 , WCF_FLOATABLE = 4 }
	Flags describing behaviour of the main window component. More...

Public Member Functions
virtual void	ShowCommands (const ibase::ICommandsProvider *commandsProvider) override

Public Member Functions inherited from iqtgui::CToolBarGuiCompBase
virtual bool	AddToMainWindow (QMainWindow &mainWindow) override
	Add this component to main window.

virtual bool	RemoveFromMainWindow (QMainWindow &mainWindow) override
	Remove this component from main window.

virtual QString	GetTitle () const override
	Get the title of the main window component.

virtual int	GetFlags () const override
	Get properties of of the window component.

Public Member Functions inherited from iqtgui::TGuiComponentBase< QToolBar >
	TGuiComponentBase ()

virtual QToolBar *	GetQtWidget () const

virtual QWidget *	CreateQtWidget (QWidget *parentPtr) override
	Create slave widget object.

Public Member Functions inherited from iqtgui::CGuiComponentBase
	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, IVisualStatus, ExtractVisualStatus)

	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, istd::IChangeable, ExtractVisualStatus)

	I_REGISTER_SUBELEMENT_INTERFACE_T (VisualStatus, imod::IModel, ExtractVisualStatus)

	CGuiComponentBase ()

bool	IsGuiShown () const

virtual bool	IsGuiCreated () const override
	Checks if the GUI has been initialized and created.

virtual bool	CreateGui (QWidget *parentPtr) override
	Initializes the GUI and connects it to the parent widget.

virtual bool	DestroyGui () override
	Releases GUI resources and disconnects from the parent.

virtual QWidget *	GetWidget () const override
	Gets access to the internal QWidget object.

virtual void	OnTryClose (bool *ignoredPtr=NULL) override
	Called when the application is attempting to close.

Public Member Functions inherited from iqtgui::TDesignSchemaHandlerWrap< Base >
	TDesignSchemaHandlerWrap ()

virtual void	EnableDesignHandler (bool enable=true)
	If enabled, listen to the design schema change events from the application context.

Public Member Functions inherited from iqtgui::CIconProvider
virtual QIcon	GetIcon (const QString &iconName) const

virtual QString	GetIconPath (const QString &iconName) const

virtual QString	GetStyleSheetPath (const QString &styleSheetPath) const

QByteArray	GetCurrentThemeId () const

void	SetThemeId (const QByteArray &themeId)

Public Member Functions inherited from istd::IPolymorphic
virtual	~IPolymorphic ()

Protected Member Functions
virtual void	OnUpdate (const istd::IChangeable::ChangeSet &changeSet) override
	Called on update of observed model.

virtual void	OnGuiCreated () override
	Called just after GUI is initialized.

virtual void	OnGuiDestroyed () override
	Called just before GUI is released.

Protected Member Functions inherited from iqtgui::CGuiComponentBase
virtual void	OnGuiDesignChanged ()

virtual void	OnGuiShown ()
	Called from widget event filter when slave widget is shown.

virtual void	OnGuiHidden ()
	Called from widget event filter when slave widget is hidden.

virtual bool	OnKeyPressed (QKeyEvent *event)
	Called from widget event filter when key is pressed.

virtual void	OnRetranslate ()
	Called when non-GUI elements (like commands) should be retranslated.

virtual void	OnGuiRetranslate ()
	Called from widget event filter when GUI should be retranslated.

void	SetStatusIcon (const QIcon &icon)
	Set status icon;.

void	SetStatusText (const QString &text)
	Set status text;.

void	SetDefaultVisualStatus ()

virtual void	OnLanguageChanged () override

virtual void	OnDesignSchemaChanged (const QByteArray &themeId) override

virtual bool	eventFilter (QObject sourcePtr, QEvent eventPtr) override

virtual void	OnComponentCreated () override

virtual void	OnComponentDestroyed () override

Protected Member Functions inherited from iqtgui::CIconProvider
virtual QIcon	CreateIcon (const QString &iconName) const

Protected Member Functions inherited from imod::TSingleModelObserverBase< ibase::ICommandsProvider >
virtual ibase::ICommandsProvider *	CastFromModel (imod::IModel *modelPtr) const

	TSingleModelObserverBase ()

ibase::ICommandsProvider *	GetObservedObject () const
	Get instance of observed object.

ibase::ICommandsProvider *	GetObjectPtr () const
	Get instance of observed object.

bool	AttachOrSetObject (ibase::ICommandsProvider *objectPtr)
	Attach to model of object or set object pointer, if no connection is possible.

virtual bool	OnModelAttached (imod::IModel *modelPtr, istd::IChangeable::ChangeSet &changeMask) override
	Callback invoked when an observable model is about to be attached to this observer.

virtual bool	OnModelDetached (imod::IModel *modelPtr) override
	Callback invoked when an observable model is about to be detached from this observer.

Protected Member Functions inherited from imod::CSingleModelObserverBase
void	SetModelPtr (imod::IModel *modelPtr)
	Set internal model pointer to specified value.

	CSingleModelObserverBase ()

virtual	~CSingleModelObserverBase ()

imod::IModel *	GetObservedModel () const
	Get access to observed model.

imod::IModel *	GetModelPtr () const
	Get access to observed model.

void	EnsureModelDetached ()
	Make sure this observer is detached.

void	SetObservedIds (const istd::IChangeable::ChangeSet &changeMask)
	Set list of ID's beeing observed.

virtual bool	IsModelAttached (const imod::IModel *modelPtr=NULL) const override
	Checks if the specified model is currently attached to this observer.

virtual void	BeforeUpdate (imod::IModel *modelPtr) override
	Callback invoked before an update of the observer's content occurs.

virtual void	AfterUpdate (imod::IModel *modelPtr, const istd::IChangeable::ChangeSet &changeSet) override
	Callback invoked after an update of the observer's content occurs.

Additional Inherited Members
Protected Types inherited from imod::TSingleModelObserverBase< ibase::ICommandsProvider >
typedef CSingleModelObserverBase	BaseClass

typedef ibase::ICommandsProvider	ModelType

Protected Types inherited from imod::CSingleModelObserverBase
typedef imod::IModel	ModelType

Protected Attributes inherited from iqtgui::CGuiComponentBase
imod::TModelWrap< VisualStatus >	m_visualStatus

Static Protected Attributes inherited from imod::CSingleModelObserverBase
static const istd::IChangeable::ChangeSet	s_undoChanges

Detailed Description

Component for construction of a tool bar for a given commands provider.

Definition at line 20 of file CCommandsToolBarGuiComp.h.

Member Typedef Documentation

◆ BaseClass

typedef CToolBarGuiCompBase iqtgui::CCommandsToolBarGuiComp::BaseClass

Definition at line 26 of file CCommandsToolBarGuiComp.h.

Member Function Documentation

◆ OnGuiCreated()

virtual void iqtgui::CCommandsToolBarGuiComp::OnGuiCreated ( )

overrideprotectedvirtual

Called just after GUI is initialized.

Reimplemented from iqtgui::CToolBarGuiCompBase.

◆ OnGuiDestroyed()

virtual void iqtgui::CCommandsToolBarGuiComp::OnGuiDestroyed ( )

overrideprotectedvirtual

Called just before GUI is released.

Reimplemented from iqtgui::CGuiComponentBase.

◆ OnUpdate()

virtual void iqtgui::CCommandsToolBarGuiComp::OnUpdate ( const istd::IChangeable::ChangeSet & changeSet )

overrideprotectedvirtual

Called on update of observed model.

This method is designed to be overload by derrived classes.

Reimplemented from imod::CSingleModelObserverBase.

◆ ShowCommands()

virtual void iqtgui::CCommandsToolBarGuiComp::ShowCommands ( const ibase::ICommandsProvider * commandsProvider )

overridevirtual

Implements ibase::ICommandsDisplayer.

The documentation for this class was generated from the following file:

Acf/Include/iqtgui/CCommandsToolBarGuiComp.h
