Component for composition/grouping of more single bitmap providers. More...

#include <CComposedBitmapProviderComp.h>

Inheritance diagram for iimg::CComposedBitmapProviderComp:

Public Types
typedef icomp::CComponentBase	BaseClass

Public Types inherited from istd::IChangeable
enum	ChangeFlags { CF_ACF_INTERNAL = 0 , CF_ALL_DATA , CF_ANY , CF_DESTROYING , CF_DELEGATED , CF_NO_UNDO }
	Data model change notification flags. More...

enum	SupportedOperations { SO_NONE = 0 , SO_OBSERVE = 1 << 0 , SO_COPY = 1 << 1 , SO_CLONE = 1 << 2 , SO_COMPARE = 1 << 3 , SO_RESET = 1 << 4 }
	Flags for supported operations. More...

enum	CompatibilityMode { CM_STRICT , CM_WITHOUT_REFS , CM_WITH_REFS , CM_CONVERT }
	Control how relationship betweeen objects are interpreted. More...

typedef QMultiMap< QByteArray, QVariant >	ChangeInfoMap

Public Member Functions
	CComposedBitmapProviderComp ()

virtual const iprm::IOptionsList *	GetBitmapListInfo () const override
	Get optional information about bitmaps in form of section constraints.

virtual int	GetBitmapsCount () const override
	Get number of produced bitmaps.

virtual const iimg::IBitmap *	GetBitmap (int bitmapIndex) const override
	Get access to produced bitmap object.

Public Member Functions inherited from icomp::CComponentBase
	CComponentBase ()
	Create component and assign it to specific context.

virtual const icomp::IComponent *	GetParentComponent (bool ownerOnly=false) const override
	Get parent of this component.

virtual void *	GetInterface (const istd::CClassInfo &interfaceType, const QByteArray &subId="") override
	Get access to specified component interface.

virtual IComponentContextSharedPtr	GetComponentContext () const override
	Get access to component context describing all application-specified component information loaded from components registry.

virtual void	SetComponentContext (const IComponentContextSharedPtr &contextPtr, const icomp::IComponent *parentPtr, bool isParentOwner) override
	Set component context of this component.

Public Member Functions inherited from istd::IPolymorphic
virtual	~IPolymorphic ()

Public Member Functions inherited from istd::IChangeable
virtual bool	IsEqual (const IChangeable &object) const
	Compare this object with another object.

virtual bool	ResetData (CompatibilityMode mode=CM_WITHOUT_REFS)
	Reset data to its default state.

virtual void	BeginChanges (const ChangeSet &changeSet)
	Starts the change transaction.

virtual void	EndChanges (const ChangeSet &changeSet)
	Ends the change transaction.

virtual void	BeginChangeGroup (const ChangeSet &changeSet)
	Starts group of changes.

virtual void	EndChangeGroup (const ChangeSet &changeSet)
	Ends group of changes.

Protected Member Functions
virtual void	OnComponentCreated () override

virtual void	OnComponentDestroyed () override

Protected Member Functions inherited from icomp::CComponentBase
bool	IsComponentActive () const
	Check if component is active.

virtual const icomp::IRealComponentStaticInfo &	GetComponentStaticInfo () const =0
	Get access to static info of this component.

Protected Member Functions inherited from istd::IChangeable
virtual void	OnBeginChanges ()
	Callback function for begin change event.

virtual void	OnEndChanges (const ChangeSet &changeSet)
	Callback function for end change event.

Protected Member Functions inherited from iprm::COptionsManager
	COptionsManager ()

void	SetFixedOptionsList (const iprm::IOptionsList *slaveSelectionConstraintsPtr)
	Set additional fixed list of options.

virtual void	ResetOptions ()
	Removes all options.

int	GetOptionIndexById (const QByteArray &optionId) const
	Get the index for the given option ID.

int	GetOptionIndexByName (const QString &optionName) const
	Get the index for the given option name.

bool	IsSelectionSerialized () const
	Check if selection is serialized.

void	SetSelectionSerialized (bool state)
	Turn on or off selection serializing.

virtual int	GetOptionsFlags () const override
	Get constraints flags.

virtual int	GetOptionsCount () const override
	Get number of managed options.

virtual QString	GetOptionName (int index) const override
	Get name of specified option.

virtual QString	GetOptionDescription (int index) const override
	Get human-readable description for an option.

virtual QByteArray	GetOptionId (int index) const override
	Get option ID.

virtual bool	IsOptionEnabled (int index) const override
	Return true if the option is enabled and can be selected.

virtual int	GetOptionOperationFlags (int index=-1) const override
	Get operation control flags of some option or whole manager.

virtual bool	SetOptionEnabled (int index, bool isEnabled=true) override
	Enables or disables a given option.

virtual bool	RemoveOption (int index) override
	Remove an option at the given index.

virtual bool	InsertOption (const QString &optionName, const QByteArray &optionId, const QString &optionDescription=QString(), int index=-1) override
	Insert an option at some position.

virtual bool	SwapOptions (int index1, int index2) override
	Swap two options.

virtual bool	SetOptionName (int index, const QString &optionName) override
	Set a new name for the option at the given index.

virtual bool	SetOptionDescription (int index, const QString &optionDescription) override
	Set a new description for the option at the given index.

virtual bool	Serialize (iser::IArchive &archive) override
	Load or store state of this object as a archive stream.

virtual int	GetSupportedOperations () const override
	Get set of flags for supported operations.

virtual bool	CopyFrom (const IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS) override

Protected Member Functions inherited from iprm::CSelectionParam
int	CalcIndexFromId (const QByteArray &optionId, int suggestedIndex=NO_SELECTION) const
	Calculate optimal index based on current selected index and ID.

bool	SyncIndexWithId ()
	Synchronize current index to optimal one.

	CSelectionParam ()

void	SetSelectionConstraints (const IOptionsList *constraintsPtr)
	Set selection constraints for this selection object.

void	SetSubselection (int selectionIndex, ISelectionParam *selectionPtr)
	Set sub-selection for a given option index.

bool	SetSelectedOptionById (const QByteArray &selectedOptionId)
	Set selection index according to a given option ID.

int	GetOptionIndexById (const QByteArray &optionId) const
	Get index of an option by ID.

ISelectionParam *	GetActiveSubselection () const
	Get sub-selection for the currently selected option.

virtual const IOptionsList *	GetSelectionConstraints () const override
	Get constraints of this parameter.

virtual int	GetSelectedOptionIndex () const override
	Get selected index.

virtual bool	SetSelectedOptionIndex (int index) override
	Set index of selected option.

virtual ISelectionParam *	GetSubselection (int index) const override
	Get sub-selection for specified option.

virtual bool	CopyFrom (const istd::IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS) override
	Copy this object from another one.

virtual istd::TUniqueInterfacePtr< istd::IChangeable >	CloneMe (CompatibilityMode mode=CM_WITHOUT_REFS) const override
	Make a copy of this object.

Protected Member Functions inherited from iser::ISerializable
virtual quint32	GetMinimalVersion (int versionId) const
	Get minimal needed version to correct storing of this data.

Additional Inherited Members
Static Public Member Functions inherited from istd::IChangeable
static const ChangeSet &	GetNoChanges ()
	Get empty set of changes.

static const ChangeSet &	GetAnyChange ()
	Get anonymous change set.

static const ChangeSet &	GetAllChanges ()
	Get anonymous change set.

static const ChangeSet &	GetDelegatedChanges ()
	Get delegated change set.

Protected Types inherited from iprm::COptionsManager
typedef CSelectionParam	BaseClass

Protected Types inherited from iprm::ISelectionParam
enum	ChangeFlags { CF_SELECTION_CHANGED = 0x67364be }
	Data model change notification flags. More...

enum	{ NO_SELECTION = -1 }

Protected Types inherited from iprm::IOptionsManager
enum	ChangeFlags { CF_OPTION_ADDED = 0x26be73a , CF_OPTION_REMOVED }
	Data model change notification flags. More...

enum	OptionOperationFlags { OOF_COUNT_FIXED = 1 , OOF_SUPPORT_RENAME = 2 , OOF_SUPPORT_INSERT = 4 , OOF_SUPPORT_DELETE = 8 , OOF_SUPPORT_SWAP = 16 , OOF_DISABLE_ALLOWED = 32 , OOF_SUPPORT_ENABLING = 64 }
	Bitwise coded flags used to find out supported features. More...

Protected Types inherited from iprm::IOptionsList
enum	ChangeFlags { CF_OPTIONS_CHANGED = 0x8263d86 , CF_OPTION_RENAMED }
	Flags for changes related to this interface. More...

enum	OptionsFlags { SCF_NONE = 0 , SCF_SUPPORT_UNIQUE_ID = 256 , SFC_DISABLE_ALLOWED = 32 }
	Flags for controlling constraints behavior. More...

Static Protected Member Functions inherited from icomp::CComponentBase
static const icomp::IRealComponentStaticInfo &	InitStaticInfo (IComponent *componentPtr)

static QByteArray	GetComponentId (const icomp::IComponentContext *componentContextPtr, const QByteArray &contextId=QByteArray())
