Common interface for a measured or sampled spectrum. More...

#include <ISpectrum.h>

Inheritance diagram for icmm::ISpectrum:

Additional Inherited Members
Public Types inherited from imath::TISampledFunction< 1, 1 >
typedef imath::TIMathFunction< istd::TIndex< ArgumentDimensions >, imath::TVector< ResultDimensions > >	BaseClass

typedef BaseClass::ArgumentType	ArgumentType

typedef BaseClass::ResultType	ResultType

typedef istd::TIndex< ArgumentDimensions >	SampleIndex

Public Types inherited from imath::TIMathFunction< istd::TIndex< ArgumentDimensions >, TVector< ResultDimensions > >
typedef istd::TIndex< ArgumentDimensions >	ArgumentType

typedef TVector< ResultDimensions >	ResultType

Public Types inherited from istd::IChangeable
enum	ChangeFlags { CF_ACF_INTERNAL = 0 , CF_ALL_DATA , CF_ANY , CF_DESTROYING , CF_DELEGATED , CF_NO_UNDO }
	Data model change notification flags. More...

enum	SupportedOperations { SO_NONE = 0 , SO_OBSERVE = 1 << 0 , SO_COPY = 1 << 1 , SO_CLONE = 1 << 2 , SO_COMPARE = 1 << 3 , SO_RESET = 1 << 4 }
	Flags for supported operations. More...

enum	CompatibilityMode { CM_STRICT , CM_WITHOUT_REFS , CM_WITH_REFS , CM_CONVERT }
	Control how relationship betweeen objects are interpreted. More...

typedef QMultiMap< QByteArray, QVariant >	ChangeInfoMap

Public Member Functions inherited from imath::ISampledFunction
double	operator[] (int index) const

Public Member Functions inherited from imath::TISampledFunction< 1, 1 >
virtual bool	CreateFunction (double *dataPtr, const ArgumentType &sizes)=0
	Create function from input data.

virtual int	GetTotalSamplesCount () const=0
	Get number of samples stored in this container.

virtual int	GetGridSize (int dimensionIndex) const=0
	Get number of samples for specified dimension.

virtual double	GetSampleAt (const SampleIndex &index) const=0
	Get sample value at the given index.

virtual istd::CRange	GetLogicalRange (int dimensionIndex) const=0
	Get logical range for the specified dimension.

virtual istd::CRange	GetResultValueRange (int dimensionIndex, int resultDimension=-1) const=0
	Get the range (boundary) of possible result values for the given axis.

virtual std::vector< double >	GetSamples () const=0
	Get all samples as a vector.

virtual int	GetArgumentDimensionality () const
	Get the number of argument components.

virtual int	GetResultDimensionality () const
	Get the number of result components.

Public Member Functions inherited from imath::TIMathFunction< istd::TIndex< ArgumentDimensions >, TVector< ResultDimensions > >
virtual bool	GetValueAt (const istd::TIndex< ArgumentDimensions > &argument, TVector< ResultDimensions > &result) const=0
	Get function value for specified argument value.

virtual TVector< ResultDimensions >	GetValueAt (const istd::TIndex< ArgumentDimensions > &argument) const=0
	Get function value for specified argument value.

Public Member Functions inherited from istd::IPolymorphic
virtual	~IPolymorphic ()

Public Member Functions inherited from istd::IChangeable
virtual int	GetSupportedOperations () const
	Get set of flags for supported operations.

virtual bool	CopyFrom (const IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS)
	Copy this object from another one.

virtual bool	IsEqual (const IChangeable &object) const
	Compare this object with another object.

virtual istd::TUniqueInterfacePtr< istd::IChangeable >	CloneMe (CompatibilityMode mode=CM_WITHOUT_REFS) const
	Make a copy of this object.

virtual bool	ResetData (CompatibilityMode mode=CM_WITHOUT_REFS)
	Reset data to its default state.

virtual void	BeginChanges (const ChangeSet &changeSet)
	Starts the change transaction.

virtual void	EndChanges (const ChangeSet &changeSet)
	Ends the change transaction.

virtual void	BeginChangeGroup (const ChangeSet &changeSet)
	Starts group of changes.

virtual void	EndChangeGroup (const ChangeSet &changeSet)
	Ends group of changes.

Public Member Functions inherited from icmm::ISpectrumInfoProvider
virtual const ISpectrumInfo *	GetSpectrumInfo () const =0

Public Member Functions inherited from iser::ISerializable
virtual bool	Serialize (IArchive &archive)=0
	Load or store state of this object as a archive stream.

virtual quint32	GetMinimalVersion (int versionId) const
	Get minimal needed version to correct storing of this data.

Static Public Member Functions inherited from istd::IChangeable
static const ChangeSet &	GetNoChanges ()
	Get empty set of changes.

static const ChangeSet &	GetAnyChange ()
	Get anonymous change set.

static const ChangeSet &	GetAllChanges ()
	Get anonymous change set.

static const ChangeSet &	GetDelegatedChanges ()
	Get delegated change set.

Protected Member Functions inherited from istd::IChangeable
virtual void	OnBeginChanges ()
	Callback function for begin change event.

virtual void	OnEndChanges (const ChangeSet &changeSet)
	Callback function for end change event.

Detailed Description

Common interface for a measured or sampled spectrum.

Purpose

ISpectrum represents spectral data - measurements of light intensity or energy across different wavelengths. This is commonly used in color science, spectroscopy, lighting simulation, and material analysis. The spectrum is stored as discrete samples in a regular 1D grid across the wavelength range.

Data Structure

A spectrum combines three interfaces to provide complete functionality:

ISampledFunction: Provides access to the discrete sample values stored in a regular grid. Use this to get/set individual sample values by index.
ISpectrumInfoProvider: Provides metadata about the spectral range (min/max wavelength) and sampling resolution. Use this to understand what the samples represent.
ISerializable: Enables saving and loading spectrum data to/from archives (files, memory, network, etc.).

Domain and Range

Domain (Wavelength): Typically measured in nanometers (nm). The spectral range (e.g., 380-780 nm for visible light) is obtained via ISpectralInfo.
Range (Intensity): Sample values are typically normalized to [0, 1] where 0 represents no energy and 1 represents maximum energy. The actual range can be queried using GetResultValueRange() from TISampledFunction.

Usage Examples

// Example 1: Creating and populating a spectrum
CSpectrum* CreateRedSpectrum()
{
       // Create spectrum for visible range (380-780 nm) with 81 samples
       CSpectrum* spectrum = new CSpectrum(380.0, 780.0, 81);

       // Set sample values - higher in red region (600-700 nm)
       int sampleCount = spectrum->GetSamplesCount();
       for (int i = 0; i < sampleCount; ++i) {
              double wavelength = spectrum->GetWavelengthForIndex(i);

              // Simple red spectrum: high intensity in red region
              double intensity = 0.0;
              if (wavelength >= 600.0 && wavelength <= 700.0) {
                     intensity = 1.0;
              } else if (wavelength >= 550.0 && wavelength < 600.0) {
                     // Gradual transition from yellow to red
                     intensity = (wavelength - 550.0) / 50.0;
              }

              spectrum->SetSampleValue(i, intensity);
       }

       return spectrum;
}

// Example 2: Reading spectrum data
void AnalyzeSpectrum(const icmm::ISpectrum* spectrum)
{
       // Get spectral range information
       const ISpectralInfo& info = spectrum->GetSpectralInfo();
       double minWavelength = info.GetMinWavelength();  // e.g., 380 nm
       double maxWavelength = info.GetMaxWavelength();  // e.g., 780 nm

       // Get sample count
       int sampleCount = spectrum->GetSamplesCount();
       qDebug() << "Spectrum has" << sampleCount << "samples";
       qDebug() << "Range:" << minWavelength << "-" << maxWavelength << "nm";

       // Find peak wavelength
       double peakIntensity = 0.0;
       int peakIndex = 0;
       for (int i = 0; i < sampleCount; ++i) {
              double intensity = spectrum->GetSampleValue(i);
              if (intensity > peakIntensity) {
                     peakIntensity = intensity;
                     peakIndex = i;
              }
       }

       // Convert peak index to wavelength
       double peakWavelength = minWavelength +
              (peakIndex * (maxWavelength - minWavelength) / (sampleCount - 1));
       qDebug() << "Peak at" << peakWavelength << "nm";
}

// Example 3: Saving/Loading spectra
void SaveSpectrum(const icmm::ISpectrum* spectrum, const QString& filename)
{
       ifile::CFileWriteArchive archive(filename);
       if (archive.IsOpen()) {
              const_cast<icmm::ISpectrum*>(spectrum)->Serialize(archive);
       }
}

void LoadSpectrum(icmm::ISpectrum* spectrum, const QString& filename)
{
       ifile::CFileReadArchive archive(filename);
       if (archive.IsOpen()) {
              spectrum->Serialize(archive);
       }
}

// Example 4: Interpolating spectral values
double GetSpectralValueAt(const icmm::ISpectrum* spectrum, double wavelength)
{
       // Use IMathFunction interface for interpolated values
       const imath::IMathFunction* function =
              dynamic_cast<const imath::IMathFunction*>(spectrum);

       if (function) {
              double value;
              if (function->Calculate(wavelength, value)) {
                     return value;
              }
       }
       return 0.0;
}

Applications

Color Science: Converting spectra to RGB or XYZ color values
Material Properties: Storing reflectance, transmittance, or emission spectra
Light Sources: Characterizing illuminants (daylight, LED, incandescent)
Spectroscopy: Storing measurement data from spectrophotometers
Rendering: Physics-based light transport in computer graphics

See also: icmm::ISpectrumInfoProvider, imath::ISampledFunction, imath::IMathFunction, icmm::CSpectrum, iser::ISerializable

Definition at line 148 of file ISpectrum.h.
