Base implementation of document manager. More...

#include <CTmplBasedDocumentManagerBase.h>

Inheritance diagram for idoc::CTmplBasedDocumentManagerBase:

Public Member Functions
	CTmplBasedDocumentManagerBase ()

virtual int	GetAllowedOperationFlags (const istd::IPolymorphic *viewPtr=NULL) const override
	Get flags of allowed operations.

virtual bool	IsFeatureSupported (int featureFlags, const QByteArray &documentTypeId) const override
	Return `true`, if the feature(s) is supported by this document template.

virtual Ids	GetDocumentTypeIds () const override
	Get list of supported document type IDs.

virtual QString	GetDocumentTypeName (const QByteArray &documentTypeId) const override
	Get human readable name of some document type ID.

virtual ifile::IFileTypeInfo *	GetDocumentFileTypeInfo (const QByteArray &documentTypeId) const override
	Get file type information object for some selected document type.

virtual Ids	GetDocumentTypeIdsForFile (const QString &filePath) const override
	Get list of supported document IDs that can handle the specified file.

virtual QString	GetDefaultDirectory (const QString &sugestedDir="", const QByteArray *documentTypeIdPtr=NULL) const override
	Return default directory for specified document type.

Public Member Functions inherited from idoc::IDocumentManager
virtual idoc::IUndoManager *	GetUndoManagerForDocument (const istd::IChangeable *documentPtr) const =0
	Return undo manager for document `documentPtr`.

virtual int	GetDocumentsCount () const =0
	Get number of opened documents.

virtual istd::IChangeable &	GetDocumentFromIndex (int index, DocumentInfo *documentInfoPtr=NULL) const =0
	Get document at specified index.

virtual int	GetViewsCount (int documentIndex) const =0
	Get number of view for specified document.

virtual istd::IPolymorphic *	GetViewFromIndex (int documentIndex, int viewIndex) const =0
	Get single view using its and document indices.

virtual istd::IPolymorphic *	GetActiveView () const =0
	Return the active document.

virtual void	SetActiveView (istd::IPolymorphic *viewPtr)=0
	Indicate that some view is active now.

virtual istd::IChangeable *	GetDocumentFromView (const istd::IPolymorphic &view, DocumentInfo *documentInfoPtr=NULL) const =0
	Return the document assigned to view.

virtual istd::IPolymorphic *	AddViewToDocument (const istd::IChangeable &document, const QByteArray &viewTypeId=QByteArray())=0
	Add a new view to the document.

virtual QByteArray	GetDocumentTypeId (const istd::IChangeable &document) const =0
	Get ID of document type managed by this object.

virtual bool	InsertNewDocument (const QByteArray &documentTypeId, bool createView=true, const QByteArray &viewTypeId="", istd::IChangeableSharedPtr newDocumentPtr=nullptr, bool beQuiet=false, bool ignoredPtr=NULL)=0
	Creates a new document with the document ID `documentTypeId`.

virtual bool	OpenDocument (const QByteArray documentTypeIdPtr=NULL, const QString fileNamePtr=NULL, bool createView=true, const QByteArray &viewTypeId="", istd::IChangeableSharedPtr documentPtr=nullptr, FileToTypeMap loadedMapPtr=NULL, bool beQuiet=false, bool ignoredPtr=NULL, ibase::IProgressManager progressManagerPtr=NULL)=0
	Opens document(s) from the file list.

virtual bool	SaveDocument (int documentIndex=-1, bool requestFileName=false, FileToTypeMap savedMapPtr=NULL, bool beQuiet=false, bool ignoredPtr=NULL, ibase::IProgressManager *progressManagerPtr=NULL)=0
	Save document.

virtual bool	SaveDirtyDocuments (bool beQuiet=false, bool *ignoredPtr=NULL)=0
	Ask user (optional) and save all dirty (changed) documents.

virtual bool	CloseDocument (int documentIndex=-1, bool beQuiet=false, bool *ignoredPtr=NULL)=0
	Close document and all its views.

virtual bool	CloseView (istd::IPolymorphic viewPtr=NULL, bool beQuiet=false, bool ignoredPtr=NULL)=0
	Close view.

Public Member Functions inherited from istd::IChangeable
virtual int	GetSupportedOperations () const
	Get set of flags for supported operations.

virtual bool	CopyFrom (const IChangeable &object, CompatibilityMode mode=CM_WITHOUT_REFS)
	Copy this object from another one.

virtual bool	IsEqual (const IChangeable &object) const
	Compare this object with another object.

virtual istd::TUniqueInterfacePtr< istd::IChangeable >	CloneMe (CompatibilityMode mode=CM_WITHOUT_REFS) const
	Make a copy of this object.

virtual bool	ResetData (CompatibilityMode mode=CM_WITHOUT_REFS)
	Reset data to its default state.

virtual void	BeginChanges (const ChangeSet &changeSet)
	Starts the change transaction.

virtual void	EndChanges (const ChangeSet &changeSet)
	Ends the change transaction.

virtual void	BeginChangeGroup (const ChangeSet &changeSet)
	Starts group of changes.

virtual void	EndChangeGroup (const ChangeSet &changeSet)
	Ends group of changes.

Public Member Functions inherited from istd::IPolymorphic
virtual	~IPolymorphic ()

Protected Member Functions
virtual const idoc::IDocumentTemplate *	GetDocumentTemplate () const

void	SetDocumentTemplate (const idoc::IDocumentTemplate *documentTemplatePtr)

Protected Member Functions inherited from istd::IChangeable
virtual void	OnBeginChanges ()
	Callback function for begin change event.

virtual void	OnEndChanges (const ChangeSet &changeSet)
	Callback function for end change event.

Additional Inherited Members
Public Types inherited from idoc::IDocumentManager
enum	ChangeFlags { CF_DOCUMENT_RENAMED = 0x834d670 , CF_DOCUMENT_CREATED , CF_DOCUMENT_REMOVED , CF_DOCUMENT_COUNT_CHANGED , CF_VIEW_ACTIVATION_CHANGED }
	Possible changes in the manager data model. More...

enum	OperationFlags { OF_FILE_NEW = 0x0001 , OF_FILE_OPEN = 0x0002 , OF_FILE_SAVE = 0x0004 , OF_FILE_SAVE_AS = 0x0008 , OF_KNOWN_PATH = 0x0010 }
	Flags describing possible operations that can be performed by the document manager. More...

typedef QMap< QString, QByteArray >	FileToTypeMap
	Map from file path to document type ID's.

Public Types inherited from istd::IChangeable
enum	ChangeFlags { CF_ACF_INTERNAL = 0 , CF_ALL_DATA , CF_ANY , CF_DESTROYING , CF_DELEGATED , CF_NO_UNDO }
	Data model change notification flags. More...

enum	SupportedOperations { SO_NONE = 0 , SO_OBSERVE = 1 << 0 , SO_COPY = 1 << 1 , SO_CLONE = 1 << 2 , SO_COMPARE = 1 << 3 , SO_RESET = 1 << 4 }
	Flags for supported operations. More...

enum	CompatibilityMode { CM_STRICT , CM_WITHOUT_REFS , CM_WITH_REFS , CM_CONVERT }
	Control how relationship betweeen objects are interpreted. More...

typedef QMultiMap< QByteArray, QVariant >	ChangeInfoMap

Public Types inherited from idoc::IDocumentTypesInfo
enum	SupportedFeatures { SF_NEW_DOCUMENT = 0x0001 , SF_EDIT_DOCUMENT = 0x0010 , SF_DEFAULT = 0xffff }
	Enumeration for supported types of operations with documents. More...

typedef QVector< QByteArray >	Ids
	Type definition for document type ID collections.

Static Public Member Functions inherited from istd::IChangeable
static const ChangeSet &	GetNoChanges ()
	Get empty set of changes.

static const ChangeSet &	GetAnyChange ()
	Get anonymous change set.

static const ChangeSet &	GetAllChanges ()
	Get anonymous change set.

static const ChangeSet &	GetDelegatedChanges ()
	Get delegated change set.

Detailed Description

Base implementation of document manager.

This implementation base on the document template concept.

See also: IDocumentTemplate

Definition at line 21 of file CTmplBasedDocumentManagerBase.h.

Constructor & Destructor Documentation

◆ CTmplBasedDocumentManagerBase()

idoc::CTmplBasedDocumentManagerBase::CTmplBasedDocumentManagerBase ( )

Member Function Documentation

◆ GetAllowedOperationFlags()

virtual int idoc::CTmplBasedDocumentManagerBase::GetAllowedOperationFlags ( const istd::IPolymorphic * viewPtr = NULL ) const

overridevirtual

Get flags of allowed operations.

Parameters

viewPtr Optional pointer to a specific view to check operations for. If NULL, checks operations for the active view/document.

Returns: Bitwise OR of OperationFlags indicating which operations are currently allowed.

Example: int flags = docMgr->GetAllowedOperationFlags();

if (flags & idoc::IDocumentManager::OF_FILE_NEW) {

// New document creation is supported

}

if (flags & idoc::IDocumentManager::OF_FILE_SAVE) {

// Saving is available

}

idoc::IDocumentManager::OF_FILE_NEW
@ OF_FILE_NEW
New document creation is supported.
Definition IDocumentManager.h:133

idoc::IDocumentManager::OF_FILE_SAVE
@ OF_FILE_SAVE
Saving documents is supported.
Definition IDocumentManager.h:135

Implements idoc::IDocumentManager.

◆ GetDefaultDirectory()

virtual QString idoc::CTmplBasedDocumentManagerBase::GetDefaultDirectory	(	const QString &	sugestedDir = `""`,
		const QByteArray *	documentTypeIdPtr = `NULL`
	)		const

overridevirtual

Return default directory for specified document type.

Parameters

suggestedDir	Template directory suggested by user or application.
documentTypeIdPtr	Optional pointer to ID of document type.

Returns: Resolved default directory path to use for file dialogs.

If suggestedDir is provided and valid, it may be used. Otherwise, the type-specific default directory is returned.

Implements idoc::IDocumentTypesInfo.

◆ GetDocumentFileTypeInfo()

virtual ifile::IFileTypeInfo * idoc::CTmplBasedDocumentManagerBase::GetDocumentFileTypeInfo ( const QByteArray & documentTypeId ) const

overridevirtual

Get file type information object for some selected document type.

Parameters

documentTypeId ID of document type as returned by GetDocumentTypeIds().

Returns: Pointer to file type info providing file extensions, filters, etc., or NULL if not available.

Implements idoc::IDocumentTypesInfo.

◆ GetDocumentTemplate()

virtual const idoc::IDocumentTemplate * idoc::CTmplBasedDocumentManagerBase::GetDocumentTemplate ( ) const

protectedvirtual

◆ GetDocumentTypeIds()

virtual Ids idoc::CTmplBasedDocumentManagerBase::GetDocumentTypeIds ( ) const

overridevirtual

Get list of supported document type IDs.

Returns: Vector of document type IDs supported by this template/manager.

Implements idoc::IDocumentTypesInfo.

◆ GetDocumentTypeIdsForFile()

virtual Ids idoc::CTmplBasedDocumentManagerBase::GetDocumentTypeIdsForFile ( const QString & filePath ) const

overridevirtual

Get list of supported document IDs that can handle the specified file.

Parameters

filePath Full path to file to check.

Returns: Vector of document type IDs that can open/handle this file.

This method determines which document types are compatible with a given file based on file extension, content analysis, or other criteria.

Implements idoc::IDocumentTypesInfo.

◆ GetDocumentTypeName()

virtual QString idoc::CTmplBasedDocumentManagerBase::GetDocumentTypeName ( const QByteArray & documentTypeId ) const

overridevirtual

Get human readable name of some document type ID.

Parameters

documentTypeId ID of document type as returned by GetDocumentTypeIds().

Returns: Localized, user-friendly name of the document type (e.g., "Text Document", "Image File").

Implements idoc::IDocumentTypesInfo.

◆ IsFeatureSupported()

virtual bool idoc::CTmplBasedDocumentManagerBase::IsFeatureSupported	(	int	featureFlags,
		const QByteArray &	documentTypeId
	)		const

overridevirtual

Return true, if the feature(s) is supported by this document template.

Parameters

featureFlags	Bitwise OR of SupportedFeatures flags to check.
documentTypeId	ID of document type to check.

Returns: True if all specified features are supported for this document type.

Implements idoc::IDocumentTypesInfo.

◆ SetDocumentTemplate()

void idoc::CTmplBasedDocumentManagerBase::SetDocumentTemplate ( const idoc::IDocumentTemplate * documentTemplatePtr )

protected

The documentation for this class was generated from the following file:

Acf/Include/idoc/CTmplBasedDocumentManagerBase.h
